Passively scans for GPS location and other privacy-related exposures in images during normal security assessments of websites via plug-ins for both Burp & ZAP. Image Location and Privacy Scanner (ILS) assists in situations where end users may post profile images and possibly give away their home location, e.g. a dating site or children's chatroom.
More information on this topic, including a white paper based on a real-world site audit given as a presentation at the New Jersey chapter of the OWASP organization, can be found at www.veggiespam.com/ils/.
This software scans images to find the GPS information inside of Exif tags, IPTC codes, and proprietary camera tags (aka "Makernotes"). Then, ILS flags the findings in the Burp Scanner or ZAP Alerts list as an information message. It would be up to the auditor to determine if location exposure is truly a security risk based on context.
There are two major branches: master which is the mainline set of releases and tng which will be a next generation set of changes that may or may not compile when you clone the repo. The master branch has tags for some released versions.
Special thanks to my contributors, listed here. Full version history can be found in the CHANGELOG.md and future ideas for implementation can be found in the TODO.md.
Configure the web browser to proxy through Burp or ZAP. Then, browse to a few sample sites to
see Alerts being raised:
- MetaData Extractor's SampleOutput page
contains some good images with interesting findings. (Note: You may need a GitHub session cookie)
- iPhone 4 shows GPS data.
- FujiFilm FinePix S1 Pro has embedded IPTC locations and keywords.
- Panasonic DMC-TZ10 shows proprietary Panasonic MakerNote tags including city, state, country along with facial recognition information, like the name and age of the person in the picture. Burp screen shot of this shown to the right and ZAP is shown below.
- DJI Phantom 4 Drone shows location, altitude, serial number, and original filenames.
- This professional photographer utilizes Exif & IPTC data in many of the full-sized (non-thumbnail) photos: Raia.com
.jpg){kind=link}
.jpg){kind=link}
The ILS jar file contains a main() function, so you can scan local files from the command line. The classpath must contain the ILS jar and its dependencies.
$ export CLASSPATH=build/libs/image-location-scanner.jar ;# for example
$ java com.veggiespam.imagelocationscanner.ILS
Image Location and Privacy Scanner v1.3
Usage: java ILS.class [-h|-m|-t] file1.jpg file2.png file3.txt [...]
-h : output results in semi-HTML
-m : output results in Markdown
-t : output results in plain text (default)
--help : detailed help
$ java com.veggiespam.imagelocationscanner.ILS [...files...]
Processing Panasonic DMC-TZ10.jpg :
Location::
Exif_GPS: 53° 8' 49.65", 8° 10' 45.1"
Panasonic: City = OLDENBURG (OLDB.)
Panasonic: Country = GERMANY
Panasonic: State = OLDENBURG (OLDB.)
Privacy::
Panasonic: Face Recognition Info = Face 1: x: 142 y: 120 width: 76 height: 76 name: NIELS age: 31 years 7 months 15 days
Panasonic: Internal Serial Number = F541005110191
Processing Panasonic Lumix DMC-LX7.jpg :
Privacy::
Panasonic: Internal Serial Number = F111311090158
Processing j2.jpg :
Location::
Exif_GPS: 40° 18' 54.92", -74° 39' 37.85"
Processing README.md : None
### With Markdown output:
$ java com.veggiespam.imagelocationscanner.ILS -m [...files...]
# ../images/Sony ILCE-7M4 (A7M4).JPG
* Privacy::
* ExifDirectoryBase: Lens Model = FE 24-70mm F2.8 GM II
* ExifDirectoryBase: User Comment = [64 values]
* Sony-Tag9050b: Internal Serial Number = 42ff00002009
# ../images/FujiFilm FinePixS1Pro (1).jpg
* Location::
* Exif_GPS: 54° 59' 22.8", -1° 54' 51"
* IPTC: Country/Primary Location Name = 'Ubited Kingdom'
* Privacy::
* ExifDirectoryBase: Image Description = Communications
* IPTC: Keywords = CommunicationsPlease confirm jar filename and classpath. Yes, "Ubited" is misspelled in the sample jpg.
The Image Location and Privacy Scanner runs as both a Burp and ZAP plug-in. The required versions of those packages are:
- Burp Pro, any recent version from PortSwigger Burp web site - the ILS plugin does not work in Burp Community Edition.
- ZAP, 2.7.x or newer from ZAP web site
Burp Application Store: Launch Burp and click Extensions tab → BApp Store → left pane → Image Location and Privacy Scanner. In the right window pane, the version and description of the plug-in will be shown; click Install or Reinstall to download and activate.
Manual Install: Go to Extensions tab → Installed → Add. Choose the type as Java, select the file for Image Location and Privacy Scanner jar file (you built or downloaded), leave Standard Output & Error as "Show in UI" and then click Next. The next screen will show the "Image Location and Privacy Scanner: plug-in version x.x" if successful or display errors on the Error tab. Click close to return to Burp.
🚨 IMPORTANT 🚨 By default, Burp hides images and this has the side effect of hiding alerts detected by ILS! Before enabling, ensure you've browsed a single page. Then, enable by clicking Target tab → Site map filtering → Show All → Apply & close. You can also fine-tune the filters by enabling the Images checkbox removing jpg, png, etc from Hide file extensions checkbox setting. After reconfiguration, the Target issues pane will show exposure alerts raised.
Note: This is a scanner-type plug-in and the scanner is disabled in Burp Community Edition. So, the plug-in will only function inside of Burp Pro or Enterprise.
The Image Location and Privacy Scanner is available in the ZAP Marketplace. Click the Add-On icon (
), then the Marketplace tab, and filter on the word "image". Once found, enable the checkbox in the "Selected" column and press "Install Selected" at the bottom. ZAP may show ILS as "Version 9.0.0" which corresponds to ILS v1.3. Once ILS is installed, it moves from Marketplace tab into the "Installed" tab.
Image Location and Privacy Scanner also can be built locally and installed via File → "Load Add-On File".
🚨 IMPORTANT 🚨 By default, ZAP hides images in the history, but ILS still scans these images for findings. If an alert is triggered, then the image and its alerts will appear in the Alerts tab but not in the History tab. To show images in the history, both with alerts and without, click Tools → Options → Display → "Process images in the HTTP requests/responses". If you have image processing completely disabled in ZAP's Options → Network → Global Exclusions → "Extension - Image" feature (née Global Exclude URL), then ILS will be unable to see the images and report on privacy issues - thus disuse this feature with images so ILS can function.
- When I use Burp or ZAP, no issues are displayed
- By default, both hide images in general usage. As such, enable image display using the directions above.
- Why do I see two sets of Exif_GPS coordinates (or another tag)
- This means the image has been embedded with multiple Exif tags of the same type. Thus more than one GPS location can appear. The ILS software displays all that are detected.
- With DJI drones, location and altitude is shown as both standard Exif GPS and using DJI's custom XMP tags
- What types of image files are scanned, why don't you scan type X
- Currently, ILS scans: "jpeg", "jpg", "png", "heif", "heic", "tiff", "tif" extensions and mime types
- ILS could possibly find leaks in "raw" or "psd" (Photoshop), but those files 1) are generally not displayed in-line on a browser and 2) can be huge and would start slowing down Burp - but Burp is already reading them. TBD.
- We generally don't see embedded leakage data in "gif", so we don't scan those.
- I see GPS location and altitude, but where is the speed, bearing, reference data, etc
- We decided to not display all the GPS data, simply the location and altitude. Submit a patch if you need all GPS info.
- You missed the serial number for Camera Type X
- Could be true. This information exposure list was built by manually looking through all Makernote tags available in MDE. If something new was added, then ILS needs to also account for it. File a bug report on GitHub and we will update in a future release.
- Another Exif scanner says
City =with no city listed orCity = ---but ILS does not show this.- It actually says "City = \0\0\0\0\0 ..." with maybe 64 nulls or "City = (single space)". ILS simply filter out strings that start with a null character (we assume someone isn't hiding data after the first null) or empty spaces.
- Some cameras and devices, like Panasonic, place "---" into fields where there is no value or the value is unknown. Other examples observed are "Off" when there is no data entered into the text field or a feature is inactive, or a single space for a name, or "-" for something. ILS does not consider these as location or privacy leaks, so they are not displayed.
- Why do you abbreviate this project "ILS" and not "ILPS"?
- The plug-in was originally called "Image Location Scanner" with
ilsin the classpath, git repo name, and my own website's whitepaper. At some point, I switched to a new dependency which gave new functions for examining photo data and I could now see Privacy leaks like serial number and ITPC encodings. Changing a classpath and git repo seemed overkill for a non-major feature, so I just kept it as "ILS".
- The plug-in was originally called "Image Location Scanner" with
- What about detection of artifacts from drone images and videos?
- Data from DJI and compatible drones is detected, but only GPS location if present. Data like speed, pitch, yaw, roll, etc are not displayed as those don't expose the location.
- Java 1.9 or newer
- Gradle 8.x or newer to build
- † Legacy Burp Extender API v2.3; uses proprietary license
- † MetaData Extractor v2.21.0; uses Apache License v2.0
† These will be auto-fetched if you build with Gradle.
The Burp plug-in is built with ./gradlew jar (or be lazy and type make). After building, the plug-in can manually be loaded into Burp.
To build for ZAP, it is easiest start by forking ZAP Extensions or my outdated repo. Then, overwrite your repo's ILS.java with the updated version. Compile with ./gradlew :addOns:imagelocationscanner:build and install imagelocationscanner-{id}.zap add-on file into ZAP via File → "Load Add-On File".
