Manipulator3D — 3-DOF Two-Link Robot Arm (Analytic IK + Pick&Place)

A Python simulation and visualization project for a 3-DOF, two-link manipulator with a fixed base in 3D space. The arm executes a simple pick-and-place loop using an analytic inverse kinematics solver and a linear end-effector trajectory.

• Joint 0 (base): revolute yaw about the +Z axis at the origin (0,0,0).
• Joints 1–2 (links): revolute pitch angles defining motion in the arm’s vertical plane (relative to the X–Y plane).
• IK: reduces the 3D target to a 2D planar problem in (r,z), solves with the law of cosines, and supports elbow-up / elbow-down branches.
• Visualization: rendered with raylib (Python bindings), including an overlay panel, editable start/goal inputs, and a suction-tool “ball” pick-and-place animation.

Runtime: Python • Rendering: raylib • IK: Closed-form

---

• About this repository
• Repository structure
• Robotics: kinematics, dynamics, and inverse kinematics
• Installing dependencies
• Running the simulator
• Repository file guide (full explanation)
• Simulation video
• Troubleshooting

---

About this repository

This project simulates a 3-DOF, two-link manipulator mounted on a fixed base at the origin:

• The base joint rotates around the Z axis (yaw).
• The two link joints rotate as pitch angles (relative to the X–Y plane) in the arm’s vertical plane.
• The end-effector (EE) tracks a sequence of target points with analytic inverse kinematics.
• A small “ball” is used to visualize a pick-and-place loop:
  1. HOME → START
  2. PICK at START (attach ball)
  3. START → GOAL
  4. PLACE at GOAL (detach ball)
  5. GOAL → HOME
  6. wait briefly and repeat

User inputs (via the overlay panel):

• START position (x y z) and GOAL position (x y z)
• Click PAUSE to edit points, then click PLAY to start a new simulation using the new points.
• Constraint enforced by IK: z must be ≥ 0
• Reachability enforced by IK: |p| must be within the arm’s reachable shell.

---

Repository structure

Manipulator3D_Python/
  README.md
  requirements.txt
  resources/
    fonts/
      README.txt  (optional font assets)
  src/
    main.py
    robot/
      robot_arm.py
    sim/
      trajectory.py
    ui/
      overlay.py
    render/
      draw_utils.py

---

Robotics: kinematics, dynamics, and inverse kinematics

1) Coordinate frames and joint conventions

• World frame origin is at the center of the base revolute joint: (0,0,0).
• Joint angles:
  • q0_yaw : rotation about +Z (sets the arm’s radial direction in the X–Y plane)
  • q1_pitch: shoulder elevation angle relative to the X–Y plane
  • q2_pitch: elbow pitch angle (relative bend in the same vertical plane)

We use the radial unit direction in the X–Y plane:

$$\mathbf{u} = \begin{bmatrix} \cos(q_0)\\\ \sin(q_0)\\\ 0 \end{bmatrix}, \quad \mathbf{k} = \begin{bmatrix} 0\\\ 0\\\ 1 \end{bmatrix}.$$

2) Forward kinematics (FK)

Let link lengths be $L_1$ and $L_2$. Then:

• Elbow position:

$$\mathbf{p}_1 = L_1\cos(q_1)\,\mathbf{u} + L_1\sin(q_1)\,\mathbf{k}$$

• End-effector position:

$$\mathbf{p}_{ee} = \mathbf{p}_1 + L_2\cos(q_1+q_2)\,\mathbf{u} + L_2\sin(q_1+q_2)\,\mathbf{k}$$

This is implemented in:

• robot/robot_arm.py → RobotArm.forward_kinematics()

3) Workspace (reachability) check

This manipulator is effectively a 2-link arm in a vertical plane, rotated by yaw. Therefore the reachable radius must satisfy:

$$r_{\min} = |L_1 - L_2|,\quad r_{\max} = L_1 + L_2$$ $$\|\mathbf{p}\| \in [r_{\min}, r_{\max}]$$

The implementation enforces:

• target.z >= 0
• |p| within [min_reach, max_reach]

4) Analytic inverse kinematics (IK): how it works here

Given target $\mathbf{p} = (x,y,z)$:

Step A — base yaw

$$q_0 = \mathrm{atan2}(y, x)$$

Step B — reduce to planar IK in $(r,z)$

$$r = \sqrt{x^2 + y^2}$$

Now solve a 2-link planar problem for the triangle formed by $L_1$, $L_2$, and $\sqrt{r^2+z^2}$.

Step C — elbow angle from law of cosines

$$\cos(q_2) = \frac{r^2 + z^2 - L_1^2 - L_2^2}{2L_1L_2}$$

Clamp to $[-1,1]$ for numerical safety, then:

$$q_2 = \pm \arccos(\cos(q_2))$$

This sign is the elbow-up / elbow-down branch selection.

Step D — shoulder angle

Define:

$$k_1 = L_1 + L_2\cos(q_2),\quad k_2 = L_2\sin(q_2)$$

Then:

$$q_1 = \mathrm{atan2}(z, r) - \mathrm{atan2}(k_2, k_1)$$

This is implemented in:

• robot/robot_arm.py → RobotArm.solve_ik()

5) Dynamics (what is implemented vs. what is prepared)

This repository is primarily a kinematic + trajectory simulator:

• The EE follows a commanded Cartesian trajectory.
• IK converts EE targets into joint angles.
• FK is used for rendering joint/link positions.

However, the code also defines mass and inertia properties for each link (uniform rod approximations):

• About center of mass:

$$I_{cm} = \frac{1}{12} mL^2$$

• About the joint at one end:

$$I_{joint} = \frac{1}{3} mL^2$$

These are computed in:

• robot/robot_arm.py → LinkParams.recompute_inertia()

Currently, those values are used for display/inspection (overlay panel) and as a foundation for extending the project to:

• forward dynamics (torques → accelerations),
• gravity and Coriolis terms,
• joint-space controllers (PD, computed torque, etc.).

---

Installing dependencies

Requirements

• Python 3.10+
• A working OpenGL-capable graphics driver
• raylib Python bindings (installed via pip)

Install (recommended: virtual environment)

From the repository root:

python -m venv .venv

Activate:

• Windows (PowerShell):

  .\.venv\Scripts\Activate.ps1

• Windows (cmd):

  .venv\Scripts\activate

• macOS/Linux:

  source .venv/bin/activate

Install dependencies:

pip install -r requirements.txt

---

Running the simulator

From the repository root:

python src/main.py

Controls / interaction

• Mouse wheel: zoom camera
• F11: toggle fullscreen
• Overlay panel:
  • PAUSE while running to edit START/GOAL
  • Type x y z values into the boxes
  • Click PLAY to restart the pick-and-place loop using the new targets

Important rules enforced:

• z >= 0
• |p| must be within the workspace shell

---

Repository file guide (full explanation)

This section explains every important file in the repository and its role.

requirements.txt

Installs raylib Python bindings.

---

src/main.py

Application entry point and runtime loop:

• configures window + camera
• holds the pick-and-place finite-state machine:
  • HOME → START → PICK → GOAL → PLACE → HOME → WAIT → LOOP
• generates a linear Cartesian trajectory between targets
• runs IK each frame to get joint angles for the current EE target
• calls FK for rendering joint/link positions
• renders:
  • robot geometry, axes, ball, suction tool
  • overlay panel (status, parameters, input boxes, play/pause)

---

src/robot/robot_arm.py

Robot model and kinematics:

• LinkParams: link length, mass, inertia approximations (rod model)
• JointAngles: the 3 joint variables (yaw + 2 pitches)
• RobotArm:
  • solve_ik()
  • forward_kinematics()
  • reach limits: min_reach, max_reach

---

src/sim/trajectory.py

A minimal trajectory generator:

• LinearTrajectory:
  • reset(from,to,duration)
  • update(dt)
  • position()
  • finished

---

src/ui/overlay.py

Overlay panel and UI logic:

• renders a semi-transparent panel
• shows:
  • link lengths, masses, inertias
  • workspace bounds
  • reachability feedback for START/GOAL
  • phase label and runtime error (if any)
• implements:
  • PLAY/PAUSE button
  • editable START and GOAL text fields (active when paused)

---

src/render/draw_utils.py

Rendering helpers using raylib primitives:

• text helpers:
  • draw_text_bold()
  • draw_text_small()
• robot visuals:
  • base pedestal
  • joint housings
  • tapered link cylinders with end caps
  • suction tool

---

Simulation video

Below is a link to the simulation video on YouTube.

---

Troubleshooting

pip install -r requirements.txt fails

• Upgrade packaging tools:

  python -m pip install --upgrade pip setuptools wheel

• Try a clean virtual environment.
• If your platform does not have a prebuilt wheel for your Python version, you may need build tooling (C compiler) to compile the extension.

Window opens but the scene is black / crashes

• Update your GPU driver.
• Ensure your system supports the OpenGL version required by the installed raylib build.

Start/Goal is “out of reach” (or rejected)

• Ensure:
  • z >= 0
  • |p| is within the workspace shell:
    • [|L1 - L2|, L1 + L2]
