…tive/camera The Scale, AffineScale, TransformPerspective, and TransformCamera grid tests produced empty cells in the screenshot pipelines because each test had a structural defect: - Scale + AffineScale crossed the axes in the scale formula (xScale=0.01*height, yScale=0.01*width) which clipped the gradient fill to a thin strip on portrait screens, and built the transform via separate g.translate + g.scale calls -- but g.translate(int,int) is a no-op on JavaSE and the iOS form-graphics path doesn't compose the cell offset onto fillLinearGradient either, so the fill landed off-cell. Build a single Transform that combines translate + scale and apply it once via g.setTransform. - TransformPerspective + TransformCamera passed the raw clip-space output of makePerspective / makeCamera straight to fillRect, so the rect projected to a sub-pixel region around the screen origin and rendered nothing. They also used the static Transform.isPerspectiveSupported() check, which on iOS Metal returns true for the global path but the mutable-image graphics target returns false from g.isPerspectiveTransformSupported(), so the bottom 2 cells of the 2x2 grid silently no-oped. Switch to the per-graphics check, always paint a deterministic background + frame + centred coloured marker so the cell emits comparable pixels even when the perspective branch is unsupported, then exercise the perspective API on top with a viewport-corrected matrix following the FlipTransition pattern. Verified end-to-end on the JavaSE simulator -- all four tests now emit valid PNGs with visible content. Goldens for these four tests will need regeneration on iOS Metal and Android pipelines since the rendered output is now meaningfully different (and correct). Co-Authored-By: Claude Opus 4.7 (1M context) <noreply@anthropic.com>
