Kubernetes on AWS Cheatsheet

text

1. Introduction to Kubernetes on AWS

What is Kubernetes?

  • Kubernetes is an open-source platform for automating containerized application deployment, scaling, and management.

Kubernetes on AWS

  • AWS offers managed Kubernetes services through Amazon EKS (Elastic Kubernetes Service), which simplifies the process of running Kubernetes clusters on AWS infrastructure.

2. Setting Up Kubernetes on AWS

Amazon EKS Overview

  • Amazon EKS is a managed service that simplifies running Kubernetes on AWS by handling the control plane and providing integration with AWS services.

Creating an EKS Cluster

  • Using AWS Management Console:

    1. Go to the Amazon EKS console.
    2. Click Create cluster.
    3. Follow the wizard to configure cluster settings, including VPC, subnets, and IAM roles.

  • Using AWS CLI:

    aws eks create-cluster --name my-cluster --role-arn arn:aws:iam::123456789012:role/EKS-Cluster-Role --resources-vpc-config subnetIds=subnet-0bb1c79de4EXAMPLE,subnet-0bb1c79de4EXAMPLE

Configuring kubectl

  • Update kubeconfig:

    aws eks update-kubeconfig --name my-cluster

3. EKS Cluster Configuration

Node Groups

  • Create Node Group Using Console:

    1. Go to the Amazon EKS console.
    2. Select your cluster.
    3. Navigate to the Compute tab and click Add Node Group.
    4. Configure settings such as instance types, scaling options, and IAM roles.

  • Create Node Group Using AWS CLI:

    aws eks create-nodegroup --cluster-name my-cluster --nodegroup-name my-node-group --scaling-config minSize=1,maxSize=3,desiredSize=2 --disk-size 20 --subnets subnet-0bb1c79de4EXAMPLE,subnet-0bb1c79de4EXAMPLE --instance-types t3.medium --node-role arn:aws:iam::123456789012:role/EKS-Node-Role

IAM Roles and Policies

  • Create IAM Roles:

    • EKS Cluster Role: Grants EKS permissions to interact with AWS services.
    • Node Instance Role: Grants permissions for the worker nodes.

  • Attach Policies:

    • AmazonEKSClusterPolicy
    • AmazonEKSWorkerNodePolicy
    • AmazonEC2ContainerRegistryReadOnly

4. Networking

VPC and Subnet Configuration

  • Create VPC:

    aws ec2 create-vpc --cidr-block 10.0.0.0/16

  • Create Subnets:

    aws ec2 create-subnet --vpc-id vpc-0bb1c79de4EXAMPLE --cidr-block 10.0.1.0/24 --availability-zone us-west-2a

  • Configure Security Groups:

    • Allow inbound traffic on port 443 (Kubernetes API server).
    • Allow outbound traffic for node communication.

Cluster Networking

  • Use Amazon VPC CNI Plugin:

    • Ensures that Kubernetes pods get IP addresses from the VPC network.
    kubectl apply -f https://raw.githubusercontent.com/aws/amazon-vpc-cni-k8s/master/config/v1.12/aws-k8s-cni.yaml

5. Deploying Applications

Deploying with kubectl

  • Create a Deployment:

    apiVersion: apps/v1
kind: Deployment
metadata:
  name: my-deployment
spec:
  replicas: 2
  selector:
    matchLabels:
      app: my-app
  template:
    metadata:
      labels:
        app: my-app
    spec:
      containers:
      - name: my-container
        image: my-image:latest
        ports:
        - containerPort: 80

  • Apply the Deployment:

    kubectl apply -f deployment.yaml

Managing Services

  • Create a Service:

    apiVersion: v1
kind: Service
metadata:
  name: my-service
spec:
  selector:
    app: my-app
  ports:
  - protocol: TCP
    port: 80
    targetPort: 80
  type: LoadBalancer

  • Apply the Service:

    kubectl apply -f service.yaml

Ingress Controllers

  • Install NGINX Ingress Controller:

    kubectl apply -f https://raw.githubusercontent.com/kubernetes/ingress-nginx/main/deploy/static/provider/aws/deploy.yaml

  • Create an Ingress Resource:

    apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: my-ingress
spec:
  rules:
  - host: myapp.example.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: my-service
            port:
              number: 80

6. Storage

EBS Volumes

  • Create and Attach an EBS Volume:

    • Create Volume:

      aws ec2 create-volume --size 10 --availability-zone us-west-2a --volume-type gp2

    • Attach Volume:

      aws ec2 attach-volume --volume-id vol-0bb1c79de4EXAMPLE --instance-id i-0bb1c79de4EXAMPLE --device /dev/xvdf

Persistent Volumes and Claims

  • Create a Persistent Volume:

    apiVersion: v1
kind: PersistentVolume
metadata:
  name: my-pv
spec:
  capacity:
    storage: 10Gi
  accessModes:
    - ReadWriteOnce
  hostPath:
    path: /mnt/data

  • Create a Persistent Volume Claim:

    apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: my-pvc
spec:
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 10Gi

7. Monitoring and Logging

CloudWatch Integration

  • Install CloudWatch Agent:

    kubectl apply -f https://s3.amazonaws.com/amazoncloudwatch-agent-kubernetes/amazon-cloudwatch-agent.yaml

  • Configure CloudWatch Logs:

    • Create log groups and streams in CloudWatch.
    • Set up IAM roles to allow Kubernetes to push logs to CloudWatch.

Prometheus and Grafana

  • Install Prometheus:

    kubectl create namespace monitoring
kubectl apply -f https://github.com/prometheus/prometheus/releases/download/v2.26.0/prometheus-2.26.0.yaml

  • Install Grafana:

    kubectl apply -f https://raw.githubusercontent.com/grafana/grafana/main/deploy/kubernetes/grafana-deployment.yaml

  • Configure Prometheus and Grafana:

    • Set up Prometheus as a data source in Grafana.
    • Import pre-built dashboards or create custom ones.

8. Security

IAM Roles for Service Accounts

  • Create IAM Role for Service Account:

    aws iam create-role --role-name my-k8s-role --assume-role-policy-document file://trust-policy.json

  • Attach Policies:

    aws iam attach-role-policy --role-name my-k8s-role --policy-arn arn:aws:iam::aws:policy/AmazonS3ReadOnlyAccess

  • Associate IAM Role with Kubernetes Service Account:

    apiVersion: v1
kind: ServiceAccount
metadata:
  name: my-service-account
annotations:
  eks.amazonaws.com/role-arn: arn:aws:iam::123456789012:role/my-k8s-role

Network Policies

  • Create a Network Policy:

    apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: allow-front-end
spec:
  podSelector:
    matchLabels:
      role: front-end
  ingress:
  - from:
    - podSelector:
        matchLabels:
          role: back-end

Secrets Management

  • Create a Kubernetes Secret:

    kubectl create secret generic my-secret --from-literal=password=my-password

  • Access Secret in Pods:

    apiVersion: v1
kind: Pod
metadata:
  name: my-pod
spec:
  containers:
  - name: my-container
    image: my-image
    env:
    - name: MY

_SECRET valueFrom: secretKeyRef: name: my-secret key: password


---

## 9. Auto-scaling and Load Balancing

### Horizontal Pod Autoscaler
- **Create Horizontal Pod Autoscaler**:
```bash
kubectl autoscale deployment my-deployment --cpu-percent=50 --min=1 --max=10

Cluster Autoscaler

  • Install Cluster Autoscaler:

    kubectl apply -f https://github.com/kubernetes/autoscaler/releases/download/<version>/cluster-autoscaler-v<version>.yaml

ELB Integration

  • Configure ELB for Load Balancing:

    • Ensure the service type is LoadBalancer.
    apiVersion: v1
kind: Service
metadata:
  name: my-service
spec:
  type: LoadBalancer
  selector:
    app: my-app
  ports:
  - protocol: TCP
    port: 80
    targetPort: 80

10. Backup and Recovery

EBS Snapshots

  • Create Snapshot:

    aws ec2 create-snapshot --volume-id vol-0bb1c79de4EXAMPLE --description "My snapshot"

  • Restore from Snapshot:

    aws ec2 create-volume --snapshot-id snap-0bb1c79de4EXAMPLE --availability-zone us-west-2a

Backup Strategies

  • Use Velero for Backup and Restore:

    • Install Velero:

      velero install --provider aws --bucket <bucket-name> --secret-file <credentials-file> --backup-location-config region=<region>

  • Create a Backup:

    velero backup create my-backup --include-namespaces my-namespace

11. Upgrades and Maintenance

Upgrading EKS Clusters

  • Upgrade Control Plane:

    • Using Console: Select your cluster and choose to upgrade.

    • Using CLI:

      aws eks update-cluster-version --name my-cluster --kubernetes-version 1.21

Upgrading Node Groups

  • Update Node Groups:

    aws eks update-nodegroup-version --cluster-name my-cluster --nodegroup-name my-node-group --release-version 1.21

Regular Maintenance

  • Monitor Cluster Health: Use AWS CloudWatch and Prometheus for monitoring.
  • Check for Vulnerabilities: Regularly scan images and clusters for security vulnerabilities.
