Docker Compose Setup Guide

docker-compose

Docker Compose is a tool for defining and running multi-container Docker applications using a single YAML file. This guide covers installation and setup for all platforms.

Important Note: Docker Compose V2

Since Docker Desktop 3.4.0 and Docker Engine 20.10.0, Docker Compose V2 is included as a plugin. The new syntax is docker compose (without hyphen) instead of docker-compose. This guide uses the modern V2 syntax.

1. Docker Compose Installation

1.1. For Windows and macOS

Docker Compose V2 comes pre-installed with Docker Desktop. If Docker Desktop is installed, you already have Docker Compose.

Verify the installation:

docker compose version

1.2. For Linux (Ubuntu/Debian)

Docker Compose V2 is included with the Docker Engine installation. If you installed Docker using the official repository, you already have it.

Verify the installation:

docker compose version

If you need to install it separately:

# Download the latest version
sudo curl -SL https://github.com/docker/compose/releases/download/v2.24.5/docker-compose-linux-x86_64 -o /usr/local/bin/docker-compose

# Apply executable permissions
sudo chmod +x /usr/local/bin/docker-compose

# Verify
docker-compose --version

1.3. For Linux (CentOS/RHEL)

Docker Compose V2 is included with Docker Engine installation. Verify:

docker compose version

1.4. Legacy Docker Compose V1 (Deprecated)

If you need the standalone V1 version (not recommended):

sudo curl -L "https://github.com/docker/compose/releases/download/1.29.2/docker-compose-$(uname -s)-$(uname -m)" -o /usr/local/bin/docker-compose
sudo chmod +x /usr/local/bin/docker-compose
docker-compose --version

2. Writing a Docker Compose YAML File

Docker Compose uses a YAML file to define services, networks, and volumes. Modern Compose files (V2) don't require a version declaration.

2.1. Basic Example: Web Server + Database

# docker-compose.yml
services:
  web:
    image: nginx:latest
    ports:
      - "8080:80"
    volumes:
      - ./html:/usr/share/nginx/html
    networks:
      - webnet
    depends_on:
      - db
    restart: unless-stopped

  db:
    image: mysql:8.0
    environment:
      MYSQL_ROOT_PASSWORD: rootpassword
      MYSQL_DATABASE: exampledb
      MYSQL_USER: user
      MYSQL_PASSWORD: password
    volumes:
      - db_data:/var/lib/mysql
    networks:
      - webnet
    restart: unless-stopped

volumes:
  db_data:
    driver: local

networks:
  webnet:
    driver: bridge

2.2. Example with Environment Variables

# docker-compose.yml
services:
  app:
    image: myapp:latest
    build: .
    environment:
      - DATABASE_URL=mysql://user:password@db:3306/exampledb
      - REDIS_URL=redis://redis:6379
    env_file:
      - .env
    ports:
      - "3000:3000"
    depends_on:
      - db
      - redis

  db:
    image: mysql:8.0
    environment:
      MYSQL_ROOT_PASSWORD: ${MYSQL_ROOT_PASSWORD}
      MYSQL_DATABASE: ${MYSQL_DATABASE}
    volumes:
      - db_data:/var/lib/mysql

  redis:
    image: redis:alpine
    ports:
      - "6379:6379"

volumes:
  db_data:

2.3. Example with Custom Network

services:
  frontend:
    image: react-app:latest
    ports:
      - "80:3000"
    networks:
      - frontend-network

  backend:
    image: api-server:latest
    ports:
      - "8080:8080"
    networks:
      - frontend-network
      - backend-network

  database:
    image: postgres:15
    networks:
      - backend-network
    volumes:
      - postgres_data:/var/lib/postgresql/data

networks:
  frontend-network:
    driver: bridge
  backend-network:
    driver: bridge
    internal: true

volumes:
  postgres_data:

3. Running Docker Compose Applications

3.1. Start Services

# Start services in foreground
docker compose up

# Start services in background (detached mode)
docker compose up -d

# Start specific service
docker compose up web

# Force rebuild of images
docker compose up -d --build

3.2. Manage Services

# List running services
docker compose ps

# View logs
docker compose logs

# Follow logs in real-time
docker compose logs -f

# View logs for specific service
docker compose logs -f web

# Stop services
docker compose stop

# Start stopped services
docker compose start

# Restart services
docker compose restart

# Restart specific service
docker compose restart web

3.3. Stop and Remove

# Stop and remove containers, networks
docker compose down

# Stop and remove containers, networks, and volumes
docker compose down -v

# Remove images as well
docker compose down --rmi all

4. Scaling Services

# Scale a service to multiple instances
docker compose up -d --scale web=3

# Note: You must remove port conflicts when scaling
# Use a load balancer or remove fixed ports

Example with scaling support:

services:
  web:
    image: nginx:latest
    # Don't specify ports when scaling
    # or use a load balancer
    deploy:
      replicas: 3

5. Common Docker Compose Commands

Build Commands

# Build services
docker compose build

# Build specific service
docker compose build web

# Build with no cache
docker compose build --no-cache

# Build and push images
docker compose build --push

Execution Commands

# Execute command in running service
docker compose exec web bash

# Execute one-time command
docker compose run web python script.py

# Run command in new container
docker compose run --rm web npm install

Maintenance Commands

# View resource usage
docker compose top

# View service logs since specific time
docker compose logs --since 1h

# Pause services
docker compose pause

# Unpause services
docker compose unpause

# Remove stopped containers
docker compose rm

# Remove all containers (including running)
docker compose rm -f

Configuration Commands

# Validate compose file
docker compose config

# View resolved configuration
docker compose config --resolve-image-digests

# Create services from compose file (without starting)
docker compose create

6. Using Environment Variables

6.1. Create .env File

# .env
MYSQL_ROOT_PASSWORD=securepassword
MYSQL_DATABASE=myapp
MYSQL_USER=dbuser
MYSQL_PASSWORD=dbpass
REDIS_HOST=redis
REDIS_PORT=6379

6.2. Reference in docker-compose.yml

services:
  db:
    image: mysql:8.0
    environment:
      MYSQL_ROOT_PASSWORD: ${MYSQL_ROOT_PASSWORD}
      MYSQL_DATABASE: ${MYSQL_DATABASE}
      MYSQL_USER: ${MYSQL_USER}
      MYSQL_PASSWORD: ${MYSQL_PASSWORD}

6.3. Override Environment Variables

# Override specific variable
MYSQL_ROOT_PASSWORD=newpassword docker compose up

# Use different env file
docker compose --env-file .env.prod up

7. Multi-Stage Builds

services:
  app:
    build:
      context: .
      dockerfile: Dockerfile
      target: production
    image: myapp:latest

8. Health Checks

services:
  web:
    image: nginx:latest
    healthcheck:
      test: ["CMD", "curl", "-f", "http://localhost"]
      interval: 30s
      timeout: 10s
      retries: 3
      start_period: 40s

  app:
    image: myapp:latest
    depends_on:
      web:
        condition: service_healthy

9. Docker Compose Best Practices

  • Use environment variables: Store sensitive data in .env files or Docker secrets
  • Use volumes for data persistence: Ensure database data persists between container restarts
  • Specify resource limits: Prevent containers from consuming all system resources
  • Use specific image versions: Avoid latest tag for production
  • Organize with multiple compose files: Use docker-compose.override.yml for local development
  • Use health checks: Ensure services are healthy before dependent services start
  • Implement proper restart policies: Use restart: unless-stopped for production
  • Label your resources: Add labels for better organization and management

Example with Best Practices

services:
  web:
    image: nginx:1.25-alpine
    ports:
      - "80:80"
    volumes:
      - ./nginx.conf:/etc/nginx/nginx.conf:ro
      - ./html:/usr/share/nginx/html:ro
    networks:
      - frontend
    restart: unless-stopped
    deploy:
      resources:
        limits:
          cpus: '0.5'
          memory: 512M
        reservations:
          cpus: '0.25'
          memory: 256M
    healthcheck:
      test: ["CMD", "wget", "--quiet", "--tries=1", "--spider", "http://localhost/health"]
      interval: 30s
      timeout: 10s
      retries: 3
    labels:
      - "com.example.description=Web server"
      - "com.example.department=IT"

networks:
  frontend:
    driver: bridge

10. Troubleshooting

Issue: Port Already in Use

# Find what's using the port
sudo lsof -i :80

# Change port in docker-compose.yml
# Or stop the conflicting service

Issue: Container Won't Start

# Check logs
docker compose logs

# Check configuration
docker compose config

# Rebuild without cache
docker compose build --no-cache

Issue: Volume Permission Issues

# Fix ownership of mounted volumes
sudo chown -R $USER:$USER ./data

# Or specify user in compose file
user: "${UID}:${GID}"
